parameters
| No | Description | Parameter |
| 1 | Working area | 1300x2500x500mm |
| 2 | Spindle type | air cooling spindle |
| 3 | Spindle power | 6.6/4.5/9.0 KW |
| 4 | Power supply | 380v ,50/60hz ,3 phases |
| 5 | Worktable | vacuum and t-slot working table |
| 6 | Spindle rotating speed | 0-18000rpm |
| 7 | Locating precision | <0.01mm |
| 8 | Min shaping character | Charater:3x3mm,letter:2x2mm |
| 9 | Operating temperature | 5°C-40°C |
| 10 | Working humidity | 30%-75%(without condensed water) |
| 11 | Working precision | ±0.03mm |
| 12 | System environment | WINDOWS 7,8,10 |
| 13 | Control configuration | syntec system with USB and PC port |
| 14 | Data transfer interface | USB/PC |
| 15 | System resolution | ±0.001mm |
| 16 | Spindle cooling way | air cooling |
| 17 | Graphic format supported | G code;*.u00,*mmg,*plt,*.nc |
| 18 | Compatible software | Artcam,UCANCAM,Type3 ,powermill ,UG |
| 19 | Cutting thickness | 0-40mm also(depends on different material) |
| 20 | Z tool censor | yes |
| 21 | Whole machine dimension | 3470x2170x1800mm |
| 22 | Net weight | 1500KG |
| 23 | Gross weight | 1600KG |
| 24 | packing | Plywood case(veneer wood case for export) |
Basic Features
9KW Air cooling spinDle
Smooth body, not easy to rust;powerful and longer lifetime.Independent research and development, rational design.
Syntec controller 6MB
The system stability is very good, the man-machine operation is friendly, easy to learn and operation, powerful function
HIWIN Guide rails
Rail works with slider ,drive the machine move ,with good bearing capacity.
JAPANESE YASKAWAservo motor
Faster speed with signal feedback .Low heat radiation .Run smoothly at ultra-low speed.Reduce the vibration ,avoid oscillation .Efficient torque enhancement .
5.5kw air vacuum pump
The air between the workpiece and the worktable surface is extracted to form a negative pressure, so as to achieve the purpose of fixing on the worktable.
Options
Oil free vacuum pump
Continuous operation, no oil, low noise, low vibration, Environmentally friendly and low energy consumption
Carousel tool changer
Fast speed, more convenient, save processing time, high control accuracy
Mist spray cooling system
Reduce the heat of material and workingtool bits .suitable for metal processing .
applications
1. Wooden door and furniture decoration industry: Solid wood door, compound door, cupboard door, large area plank plane carving, wood carve designs, board type furniture engraving, archaize annatto furniture engraving, solid wood art mural engraving and so on.
