parameters
| No | Deacription | Parameter |
| 1 | Rotary axis | 4pcs 125x2000mm |
| 2 | Drive and motor | Stepper system |
| 3 | Guide rails | Taiwan Square Guide Rail |
| 4 | Spindle power | 4pcs 2.2kw water cooling spindle |
| 5 | Spindle speed | 24000rpm |
| 6 | Spindle cooling type | Water cooling |
| 7 | Inverter | Fuling |
| 8 | Machine body | Welded structurer steel pipe |
| 9 | Software envorionment | WindowsXP/Win 7/ Win 10 |
| 10 | Control systems | Mach3 |
| 11 | Compatible files format | G code |
| 12 | Compatible software | UcancamV8/Type3/Artcam etc. |
| 13 | Working voltage | AC380V/50-60HZ 3Phase |
| 14 | Net weight/Gross weight | 1000kg/1200kg |
| 15 | Optional | 3.0Kw water cooling spindle |
| 16 | Optional | DSP Richauto A11 |
| 17 | Optional | Servo system,More heads |
Basic Features
2.2KW water cooling spindle ,0-24000rpm
Smooth body, not easy to rust;powerful and longer lifetime.Independent research and development, rational design.
Mach3 controller ,ethernet connection .
Support Winxp win7 win10. doesn’t need driver installed. Aluminum housing, shielding interference, stable and reliable
Hiwin square guide rail
Rail works with slider ,drive the machine move ,with good bearing capacity.
stepper motor and Leadshine stepper driver
Without A/D conversion, the digital pulse signal can be directly convertedinto angular displacement. Cheap and good performance ,function is to drive the axis movement as parameter setting.
Steadily thimble
Fix the working materials ,not loosen during machine running .Ensure high precision and performance .
Chuck with tray
Suitable for fixing round material ,different diameter for detail request .With extra tray on chuck ,can fix big diameter goods.
Options
dust collector
All dust residue is controlled with a small area by employing the brush of the dust hood on the spindle to get the residue vacuumed away into the dust
Air cooling spindle
High precision chuck balanced nut, with powerful fan high-efficiency refrigeration.High precision steel ball retainer; grease lubrication high temperat
Leadshine servo motor
Fast speed, more convenient, save processing time, high control accuracy
DSP controller
featuring delicate appearance,powerful functionality and flexible operation.
applications
The machine is widely used in carving cubic and column work piece such as wooden table legs,the human body,figure of Buddha,the goddess of mercy,sculpture,handicrafts,stair handrail,cylinder Musical Instruments; working on flat materials function is optional.
