parameters
| No | Description | Parameter |
| 1 | Working area | 500x300x600x200mm |
| 2 | Whole structure | Heavy duty steel body |
| 3 | Table surface | Special custom-made table |
| 4 | Movement parts | all axis TBI Ball screw transmittion |
| 5 | Spindle | 2.2 Kw water cooling Spindle / optional |
| 6 | Spindle speed | 24000 RPM |
| 7 | Drive Motor | Stepper motor/leadshine easy servo/optional |
| 8 | Max. Rapid Travel Rate | 33000 mm/min |
| 9 | Max. Working speed | 25000mm/min |
| 10 | Control System | Mach3 controller/DSP optional |
| 11 | Software | Type3/Artcam/Ucancan/optional |
| 12 | Machine precision | ±0.01mm |
| 13 | Repositioning precision | ±0.03mm |
| 14 | Command language | G code |
| 15 | Working voltage | AC 220v/380v |
| 16 | Package size | 1500x2950x2100mm |
| 17 | Weight | 1100kg/1300kg(net/gross) |
| 18 | Dust Collector | Optional |
| 19 | Color | Blue-white/Optional |
| 20 | Computer Interface | USB |
| 21 | Flash Memory | 128M(U Disk) |
| 22 | Collet | ER16/20 |
| 23 | X,Y Resolution | <0.01mm |
| 24 | Software Compatibility | Type3/UcancanmeV9/Artcam |
| 25 | Running Enviroment Temperature | 0 - 45 Centigrade |
| 26 | Relative Humidity | 30% - 75% |
Basic Features
2.2KW water cooling spindle ,6 pieces with the machine
Smooth body, not easy to rust;powerful and longer lifetime.Independent research and development, rational design.
Mach3 controller ,ethernet connection .
Support Winxp win7 win10. doesn’t need driver installed. Aluminum housing, shielding interference, stable and reliable
Hiwin square guide rails
Rail works with slider ,drive the machine move ,with good bearing capacity.
Stepper motor NEMA34 and Leadshine driver M860H
Without A/D conversion, the digital pulse signal can be directly convertedinto angular displacement. Cheap and good performance ,function is to drive the axis movement as parameter setting.
Special design for racket
500x300mm working area for every racket ,suitable for most size request .Steadily fixture and useful fuction .
Ball screw transmission
All axis with TBI ball screw ,ensure high precision and best finish goods .
Options
dust collector
All dust residue is controlled with a small area by employing the brush of the dust hood on the spindle to get the residue vacuumed away into the dust
Air cooling spindle
High precision chuck balanced nut, with powerful fan high-efficiency refrigeration.High precision steel ball retainer; grease lubrication high temperat
Leadshine servo motor
Fast speed, more convenient, save processing time, high control accuracy
DSP controller
featuring delicate appearance,powerful functionality and flexible operation.
applications
This machine is professional for beach racket making processing, mainly use on carbon fiber, wood, MDF, PP etc. materials professional for racket drilling holes, scientific and reasonable with high accuracy and high quality.
